5-3/4 in. Commercial Hollow Metal Frame Header

$0.00

Size

Clear

Warranty:
1-year limited warranty

Material:
Steel

16 gauge standard
- Available in 12 and 14 gauges
Double, unequal, rabbeted profile standard
- Available in cased opened, single rabbet, equal rabbet, communicating, double egress, and other custom profiles
Cold rolled steel standard
- Available in A40, A60 galvannealed and G90 galvanized steel
Mesker grey primer standard
- Available unprimed (galvanized and galvannealed) and factory prefinished in thousands of colors
Anchoring options
- Anchoring options: wire anchors, masonry t anchors, universal anchors, steel stud anchors, punch and dimple tube anchors, existing wall anchors
Knocked down construction standard
- Available face welded
- Available face and throat welded
Exclusive F-series frame design includes:
- 3/16″ 7 gauge projection welded-one piece hinge reinforcements
- Factory installed plaster guards on hinge and strike reinforcements
- Tacked in 16 gauge floor anchors
- Precision brake forming for crisp profile bends
- 14-gauge projection-welded- one piece strike reinforcements
- Mitered corners with strong 4 tab interlocking system
- Furnished with rubber mutes- 3 per strike jamb
- Embossed UL label on hinge jamb for up to 3 hour fire rating
Built to meet and exceed ADA, ANSI, ASTM, and SDI standards
