Stainless Steel Entry Thumbpiece Trim

EACH TP-08 ENTRY US32D DESIGN HARDWARE LOCK

• Stainless Steel Construction
• Steel, Zinc Dichromated chassis
• Pull Plate: 3″ Wide x 13 3/4″ Height x 1/16″ thick
• Pull: 3/4″ diameter hollow x 6″ ctc x 2 7/16″ projection
• Application: Pull trim with thumbpiece control option for 1000R & 2000R (Not recommended for SVR devices as rods can be hard to lift with thumbpiece)
• Thru bolted design thru bolts to head of exit device and to door with finish washer. Will cover 161 door prep
• Non-Handed
• Door thickness: 1 3/4″ standard – Add the suffix -TD for 2″ thick door
• Functions: 02DT Dummy, 08 Entry, 08A Passage
• Cylinder: 1 1/4″ Mortise Cylinder with std. cam (included) – 6 Pin Brass, C Kwy, with 2 Keys
• Optional Cylinder: 1 3/8″ Mortise cylinder housing for 6 or 7 pin Small format IC core (less core)
• Optional Keyways: 11 Popular competitor keyways available with replacement cylinders
• Finishes: US3, US4 , US10B, US26, US32D
• Limited Lifetime Warranty
