8-3/4 in. Commercial Hollow Metal Frame Header

16 Gauge Standard

• Available in 12 and 14 gauges

Double, Unequal, Rabbeted Profile Standard

• Available in Cased Opened, Single Rabbet, Equal Rabbet, Communicating, Double Egress, and other custom profiles

Cold Rolled Steel Standard

• Available in A60 Galvannealed and G90 Galvanized Steel

Mesker Grey Primer Standard

• Available unprimed (Galvanized and Galvannealed) and factory prefinished in thousands of Sherwin Williams Colors

Anchoring Options

• Anchoring Options: Wire Anchors, Masonry T anchors, Universal Anchors, Steel stud Anchors, Punch and Dimple Tube Anchors, Existing Wall Anchors

Knocked Down Construction Standard

• Available Face Welded
• Available Face and Throat welded

Exclusive F-Series Frame Design Includes:

• 3/16″ 10 gauge projection welded-one piece hinge reinforcements
• Factory Installed plaster guards on hinge and strike reinforcements
• Tacked in 16 gauge floor anchors
• Precision brake forming for crisp profile bends
• 14-gauge projection-welded- one piece strike reinforcements
• Mitered Corners with strong 4 tab interlocking system
• Furnished with rubber mutes- 3 per strike jamb
• Embossed UL label on hinge jamb for up to 3 hour fire rating

Built to meet and exceed ADA, ANSI, ASTM, and SDI standards
